bitpit::VolOctreeMapper Class Reference

The VolOctreeMapper is the class to map two meshes of class VolOctree. More...

Inheritance diagram for bitpit::VolOctreeMapper:

Collaboration diagram for bitpit::VolOctreeMapper:

Public Member Functions
	VolOctreeMapper (const VolOctree *referencePatch, const VolOctree *mappedPatch, MPI_Comm communicator)
void	adaptionAlter (const std::vector< adaption::Info > &adaptionData, bool reference=true, bool inverseFilled=false) override
void	adaptionCleanup () override
void	adaptionPrepare (const std::vector< adaption::Info > &adaptionData, bool reference=true) override
bool	checkPartition () override
void	clearPartitionMapping ()
std::unordered_map< int, std::vector< long > >	getReceivedMappedIds () const override
std::unordered_map< int, std::vector< long > >	getReceivedReferenceIds () const override
std::unordered_map< int, std::vector< long > >	getSentMappedIds () const override
std::unordered_map< int, std::vector< long > >	getSentReferenceIds () const override
Public Member Functions inherited from bitpit::VolumeMapper
void	clear ()
void	clearInverseMapping ()
void	clearMapping ()
const bitpit::PiercedStorage< mapping::Info > &	getInverseMapping () const
const VolumeKernel *	getMappedPatch () const
const bitpit::PiercedStorage< mapping::Info > &	getMapping () const
const VolumeKernel *	getReferencePatch () const
void	initialize (bool fillInv=false)

Additional Inherited Members
Protected Member Functions inherited from bitpit::VolumeMapper
	VolumeMapper (const VolumeKernel *referencePatch, const VolumeKernel *mappedPatch, MPI_Comm communicator)
void	freeCommunicator ()
MPI_Comm	getCommunicator () const
void	initializeCommunicator (MPI_Comm communicator)
bool	isCommunicatorSet () const
Protected Attributes inherited from bitpit::VolumeMapper
MPI_Comm	m_communicator
PiercedStorage< mapping::Info >	m_inverseMapping
const VolumeKernel *	m_mappedPatch
PiercedStorage< mapping::Info >	m_mapping
int	m_nProcs
std::unordered_map< long, mapping::Info >	m_previousMapping
int	m_rank
const VolumeKernel *	m_referencePatch

Detailed Description

The VolOctreeMapper is the class to map two meshes of class VolOctree.

The VolOctreeMapper allows to map meshes of class VolOctree. The meshes are defined as a reference mesh and a mapped mesh.

The object can provide a direct mapper and a inverse mapper between only the Cells of the meshes.

The information given by a mapper object is analogous to an adaptation info to adapt the mapped mesh to the reference one (or vice versa in case of inverse mapper).

The two meshes have to be imperatively linked at declaration of the mapper object.

To compute the mapper the first time call initialize method. Then, if the reference mesh OR the mapped mesh (one at a time) is adapted, the mapper can be adapted together by passing the adaptation information to the prepare and alter methods. A load-balancing procedure is not allowed, i.e. the mapper has to be entirely recomputed after a load-balance of a mesh.

Note. The domain of the two meshes has to be the same, i.e. the meshes must have same origin and length.

Definition at line 41 of file voloctree_mapper.hpp.

Constructor & Destructor Documentation

VolOctreeMapper()

bitpit::VolOctreeMapper::VolOctreeMapper	(	const VolOctree *	referencePatch,
		const VolOctree *	mappedPatch,
		MPI_Comm	communicator )

Constructor.

Parameters

[in]	referencePatch	is the reference mesh
[in]	mappedPatch	is the mapped mesh
[in]	communicator	is the MPI communicator

Definition at line 68 of file voloctree_mapper.cpp.

Member Function Documentation

adaptionAlter()

void bitpit::VolOctreeMapper::adaptionAlter ( const std::vector< adaption::Info > & adaptionData, bool reference = true, bool inverseFilled = false )

overridevirtual

Update the mapper after an adaption of the reference OR the mapped mesh.

The adaptationPrepare method of the mapper has to called before the adaptation of the mesh.

Parameters

[in]	adaptionData	are the adaptation info that describe the changes of the patch
[in]	reference	if set to true the reference mesh will be adapted, is set to false the mapped one will be adapted
[in]	inverseFilled	if set to true the inverse mapped was filled during the mesh mapper computing. If the adapted mesh is the mapped one, the inverse mapper has to be necessarily filled during the first computation in initialization)

Implements bitpit::VolumeMapper.

Definition at line 151 of file voloctree_mapper.cpp.

adaptionCleanup()

void bitpit::VolOctreeMapper::adaptionCleanup ( )

overridevirtual

Clear the mapper updating internal structures.

Implements bitpit::VolumeMapper.

Definition at line 163 of file voloctree_mapper.cpp.

adaptionPrepare()

void bitpit::VolOctreeMapper::adaptionPrepare ( const std::vector< adaption::Info > & adaptionData, bool reference = true )

overridevirtual

Prepare the mapper for an adaption of the reference OR the mapped mesh.

The adaptation of only one mesh at time is allowed. Calling this method is mandatory to perform an update of the mapper after an adaptation.

Parameters

[in]	adaptionData	are the adaptation info that describe the changes of the patch
[in]	reference	if set to true the reference mesh will be adapted, is set to false the mapped one will be adapted

Implements bitpit::VolumeMapper.

Definition at line 106 of file voloctree_mapper.cpp.

checkPartition()

bool bitpit::VolOctreeMapper::checkPartition ( )

overridevirtual

Check if the reference and the mapped meshes have the same geometric partitioning.

Returns

Returns true if the meshes have identical geometric partitioning, false otherwise.

Implements bitpit::VolumeMapper.

Definition at line 1127 of file voloctree_mapper.cpp.

clearPartitionMapping()

void bitpit::VolOctreeMapper::clearPartitionMapping

(

)

Clear partition mapping members

Definition at line 81 of file voloctree_mapper.cpp.

getReceivedMappedIds()

std::unordered_map< int, std::vector< long > > bitpit::VolOctreeMapper::getReceivedMappedIds ( ) const

overridevirtual

Get the list of the octants of the partitions of the mapped mesh, different from the local rank, overlapped to the local partition of the reference mesh.

Returns

Returns the map with for each rank (key) the list of the octants (argument) of the mapped mesh overlapped with the local partition of the reference mesh.

Implements bitpit::VolumeMapper.

Definition at line 752 of file voloctree_mapper.cpp.

getReceivedReferenceIds()

std::unordered_map< int, std::vector< long > > bitpit::VolOctreeMapper::getReceivedReferenceIds ( ) const

overridevirtual

Get the list of the octants of the partitions of the reference mesh, different from the local rank, overlapped to the local partition of the mapped mesh.

Returns

Returns the map with for each rank (key) the list of the octants (argument) of the reference mesh overlapped with the local partition of the mapped mesh.

Implements bitpit::VolumeMapper.

Definition at line 807 of file voloctree_mapper.cpp.

getSentMappedIds()

std::unordered_map< int, std::vector< long > > bitpit::VolOctreeMapper::getSentMappedIds ( ) const

overridevirtual

Get the list of the octants of the local partition of the mapped mesh overlapped to a different partition of the reference mesh.

Returns

Returns the map with for each rank (key) the list of the octants (argument) of the mapped mesh overlapped with the partition (rank) of the reference mesh.

Implements bitpit::VolumeMapper.

Definition at line 844 of file voloctree_mapper.cpp.

getSentReferenceIds()

std::unordered_map< int, std::vector< long > > bitpit::VolOctreeMapper::getSentReferenceIds ( ) const

overridevirtual

Get the list of the octants of the local partition of the reference mesh overlapped to a different partition of the mapped mesh.

Returns

Returns the map with for each rank (key) the list of the octants (argument) of the reference mesh overlapped with the partition (rank) of the mapped mesh.

Implements bitpit::VolumeMapper.

Definition at line 775 of file voloctree_mapper.cpp.

---

The documentation for this class was generated from the following files:

• src/voloctree/voloctree_mapper.hpp
• src/voloctree/voloctree_mapper.cpp
